| Rated load mass (kg) |
2500 |
| Loading bucket capacity (m³) |
1.2 |
| Machine weight (kg) |
10200 |
| Maximum unloading height (mm) |
3120 |
| Unloading distance (mm) |
870 |
| Gearbox Model |
315Y |
| Gearbox transmission mode |
Hydraulic torque converter |
| Low speed gear (km/h) |
5 |
| High gear (km/h) |
35 |
| Maximum steering angle |
Soil 18° |
| Length (mm) |
6400 |
| Width (mm) |
2500 |
| Height (mm) |
3080 |
| Bucket width (mm) |
2460 |
| Wheelbase (mm) |
2350 |
| Wheelbase (mm) |
2030 |
| Minimum ground clearance (mm) |
380 |
| Engine Model |
4105 Supercharger |
| Engine Manufacturer |
Weichai |
| Rated power (kw) |
70 |
| Rated speed (r/min) |
2200 |
| Drive axle model |
ZL30 Steering Axle ZL30 |
| tire |
16.9-28 |
| Service brakes |
Gas Cap Oil |
| Parking brake |
Handbrake caliper disc |
| Turning radius (outer edge of bucket) (mm) |
6420 |
| Bucket capacity (m³) |
0.3 |
| Maximum digging depth of bucket (mm) |
3510 |
|
|
| Maximum digging radius of bucket (mm) |
5565 |
| Maximum unloading height of bucket (mm) |
3725 |
| Maximum digging height of bucket (mm) |
5370 |
| Lifting force at maximum digging radius of bucket (kg) |
1220 |
| Name/Category |
XF 105-25 |
| Rated load mass (kg) |
2500 |
| Loading bucket capacity (m³) |
1.2 |
| Machine weight (kg) |
10200 |
| Maximum unloading height (mm) |
3120 |
| Unloading distance (mm) |
870 |
| Gearbox Model |
315Y |
| Gearbox transmission mode |
Hydraulic torque converter |
| Low speed gear (km/h) |
5 |
| High gear (km/h) |
35 |
| Maximum steering angle |
Soil 18° |
| Length (mm) |
6400 |
| Width (mm) |
2500 |
| Height (mm) |
3080 |
| Bucket width (mm) |
2460 |
